Quick Sizing Guide for Metal Table Legs and Bases
Width
A quick, general rule of thumb is to take the overall width of your tabletop and subtract 24″ to get the width of your table base. Make sure the legs do not go below these minimum widths:
- Dining heightย – 20″ width minimum
- Counter heightย – 24″ width minimum
- Bar heightย – 28″ width minimum
For any metal table base designs that taper in at the floor, add 6-8″ to the above minimums for the minimum base width since the width is measured at the widest point of the base, at the top, and they taper in 6″ to 8″ at the floor.
Length (if applicable)
Some of our metal trestle bases are intended for use with square or round tops, so the “width” of the base is a measure of the overall diameter of the base and length is not an option. For base styles that specify both width and length, the length of the base will depend on how much overhang your tabletop can support. As a general rule of thumb, follow the below max overhang recommendations for the below top materials:
- Wood Topย – Top length minus 36″
- Stone Topย – Top length minus 24″
- Glass Topย – Top length minus 24″
Top thicknesses and strengths vary, so it is ALWAYS best to get a recommendation from the fabricator of your tabletop for overhang allowances. Also make sure the length of the base does not drop below the above width minimums for stability.
Height
- Dining heightย is finished at 30″, so subtract the thickness of your tabletop from 30″ to get the height of the table base. Round down to the nearest inch to account for the included leveling feet.
- For counter height, subtract the thickness of the tabletop from 36″.
- For bar height, subtract the thickness of the top from 42″.
Coffee tables, side tables, and bench bases
- You typically want the width of the base for smaller sized builds to be just a couple inches smaller than the top.
- Benches typically have a finished height that is 12″ less than the table height. So subtract the thickness of the top from this measurement to get the height of the base.
- Coffee tables typically have a finished height equal to, or a couple inches below the surrounding seating height. Usually around 18″ to 20″ tall.
- Side tables typically have a finished height equal to, or slightly below the surrounding arm rest height of nearby seating.
Tubing Size
- 1″ tubeย – Reserved for small, lightweight tables, such as side tables or coffee tables
- 1.5″ or 1×2 rectangular tubeย – Suitable for smaller tables, dining tables with a minimalistic style, or bench bases
- 2″ or 1×3 rectangular tubeย – Most common size material, suitable for most applications
- 3″ or 2×3 rectangular tubeย – Suitable for heavier or larger tabletops, or where a more prominent look is desired for the metal table base
- 4″ or 2×4 rectangular tubeย – Gives a massive look to the table base, suitable for the heaviest and largest of tabletops.
For a more complete guide, see ourย Base Sizing Guideย for more information or feel free toย Contact Usย for more our recommendation.
Rolled Arch Style Metal Table Base
This metal base has a unique design, utilizing simple geometric shapes to accomplish a simple, yet functional table base. This base works for dining tables, conference tables, desks, and more! The free standing design of the base also allows it be used for all top materials, include wood, stone, or glass. This metal table base was nominated for the Furniture Design Award for 2019!
This metal table base is made from heavy duty 1/2″ x 4″ steel flat bar for the main arches with a 1″ square tubing frame for the top support. This base comes standard with mounting tabs with slotted holes for mounting. For glass top applications, there are no mount plates or holes, and the top of the base is finish smooth for a seamless appearance through the glass. We also include rubber bumpers for the glass to rest on. Felt pads are also included for floor protection. Made in the USA, with US sourced steel.
Due to the geometry of this base, the main arches must be at least twice as long as the height of the base, which creates a full semi-circle. The arches can be longer than this, but they cannot be any shorter.
All products undergo extensive quality control checks to ensure your products are made as specified and come free of any defects or sharp edges. Please Contact Us if you have any questions about the sizing, details, or applications of this base or see our Base Sizing Guide for additional information.
Don’t see what you’re looking for? Contact Us if the size you are looking for is not shown, or if you would like to discuss making something custom.
